200G FR4 Tx
200G FR4 Tx
Features
- Data Rate：4×50Gbps PAM4; Compatible with 4×25Gbps NRZ
- Integrated Mux：1271/1291/1311/1331 nm
- Insertion Loss per channel：<5.5 dB
- Electro-Optical Bandwidth：>20 GHz
- Differential Impedance：100 ohms
- Differential Drive Voltage：2.0 Vppd
- Extinction Ratio：>5dB
- Operating Case Temperature：0~70 ℃
Applications
- 200G FR4 Optical Transceiver and 100G CWDM4 Optical Transceiver
Applications
Autonomous Driving
Coherent Doppler LiDAR for Wind Sensing
3D Laser Scanning and Laser Ranging
Phase-sensitive Optical Time Domain Reflectometer (Φ-OTDR) sensing system
Brillouin OTDR (BOTDR) Sensing System
